Blaze Audio PowerZone Connect 3004 — 3000W 4-Channel DSP Installation Amplifier

The Blaze Audio PowerZone Connect 3004 is a 3,000 W, 4-channel DSP installation amplifier in a full-rack 2U chassis — serious per-channel power with a full-matrix DSP and web-app control for larger commercial systems.

Verified specs (per Blaze/Sonance):

• 3,000 W total system power: 4×750 W into 2/4Ω (4×400 W into 8Ω), bridgeable to 2×1,500 W
• Hi-Z constant-voltage: 2×1,200 W at 70 V or 2×1,500 W at 100 V, selectable per channel
• Full-matrix DSP via the built-in PowerZone Control web app — onboard Wi-Fi access point or RJ45
• 4 balanced analog inputs plus stereo S/PDIF digital I/O with master/slave linking to additional amps
• Configurable GPIO for external control
• Pascal UMAC Class-D with UREC universal power supply (PFC); ErP and Energy Star compliant
• 2U full-rack chassis; 5-year warranty

Ideal for: subwoofer and high-output zones in clubs, event venues and large commercial spaces — anywhere 4 channels of real power plus onboard processing replaces an amp-plus-DSP rack. System design, installation and commissioning available through LAMIGA.
